NDUFB9 Recombinant Monoclonal Antibody

Code CSB-RA568204A0HU
Size US$210
Order now
  • Western Blot
    Positive WB detected in: MCF-7 whole cell lysate(30µg), PC-3 whole cell lysate(30µg), K562 whole cell lysate(30µg), HepG2 whole cell lysate(30µg), HeLa whole cell lysate(30µg), A549 whole cell lysate(30µg), HEK293 whole cell lysate(30µg), Rat stomach tissue lysate(30µg)
    All lanes: NDUFB9 antibody at 1:1000
    Secondary
    Goat polyclonal to rabbit IgG at 1/50000 dilution
    Predicted band size: 22 kDa
    Observed band size: 22 kDa
    Exposure time: 1min
  • IHC image of CSB-RA568204A0HU diluted at 1:100 and staining in paraffin-embedded human melanoma cancer performed on a Leica BondTM system. After dewaxing and hydration, antigen retrieval was mediated by high pressure in a citrate buffer (pH 6.0). Section was blocked with 10% normal goat serum 30min at RT. Then primary antibody (1% BSA) was incubated at 4°C overnight. The primary is detected by a Goat anti-rabbit polymer IgG labeled by HRP and visualized using 0.05% DAB.
  • IHC image of CSB-RA568204A0HU diluted at 1:100 and staining in paraffin-embedded human stomach tissue performed on a Leica BondTM system. After dewaxing and hydration, antigen retrieval was mediated by high pressure in a citrate buffer (pH 6.0). Section was blocked with 10% normal goat serum 30min at RT. Then primary antibody (1% BSA) was incubated at 4°C overnight. The primary is detected by a Goat anti-rabbit polymer IgG labeled by HRP and visualized using 0.05% DAB.
Have Questions? Leave a Message or Start an on-line Chat

Product Details

Uniprot No.
Target Names
Alternative Names
B22 antibody; CI B22 antibody; CI-B22 antibody; complex I B22 subunit antibody; Complex I-B22 antibody; DKFZp566O173 antibody; FLJ22885 antibody; I B22 antibody; LYR motif containing protein 3 antibody; LYR motif-containing protein 3 antibody; LYRM3 antibody; NADH dehydrogenase (ubiquinone) 1 beta subcomplex, 9, 22kDa antibody; NADH dehydrogenase [ubiquinone] 1 beta subcomplex subunit 9 antibody; NADH ubiquinone oxidoreductase B22 subunit antibody; NADH-ubiquinone oxidoreductase B22 subunit antibody; NDUB9_HUMAN antibody; Ndufb9 antibody; UQOR22 antibody
Species Reactivity
Human, Rat
Immunogen
A synthesized peptide derived from human NDUFB9
Immunogen Species
Homo sapiens (Human)
Conjugate
Non-conjugated
Clonality
Monoclonal
Isotype
Rabbit IgG
Clone No.
4D7
Purification Method
Affinity-chromatography
Concentration
It differs from different batches. Please contact us to confirm it.
Buffer
Rabbit IgG in 10mM phosphate buffered saline , pH 7.4, 150mM sodium chloride, 0.05% BSA, 0.02% sodium azide and 50% glycerol.
Form
Liquid
Tested Applications
ELISA, WB, IHC
Recommended Dilution
Application Recommended Dilution
WB 1:500-1:2000
IHC 1:50-1:200
Troubleshooting and FAQs
Storage
Upon receipt, store at -20°C or -80°C. Avoid repeated freeze.
Lead Time
Basically, we can dispatch the products out in 1-3 working days after receiving your orders. Delivery time maybe differs from different purchasing way or location, please kindly consult your local distributors for specific delivery time.
Description

NDUFB9, also known as Complex I-B22 subunit or LYRM3, is an essential component of mitochondrial Complex I, the largest enzyme of the oxidative phosphorylation system. As part of the NADH-ubiquinone oxidoreductase complex, NDUFB9 plays a critical role in cellular energy metabolism and electron transport chain function. This makes it a valuable target for researchers investigating mitochondrial disorders, metabolic dysfunction, and the bioenergetic alterations that characterize many disease states including cancer.

This recombinant monoclonal antibody, generated from clone 4D7 in rabbit host, offers the reproducibility and consistency that demanding research applications require. Because the antibody sequence is defined and produced recombinantly, you can expect reliable performance across experiments and over time, eliminating the lot-to-lot variability that can complicate long-term studies or multi-site collaborations.

Validation data demonstrates robust performance across multiple experimental platforms. In western blot applications, this antibody detects a clean band at the expected 22 kDa molecular weight across a diverse panel of human cell lines including MCF-7, PC-3, K562, HepG2, HeLa, A549, and HEK293, as well as rat stomach tissue lysate, confirming cross-species reactivity between human and rat samples. For immunohistochemistry, the antibody has been validated in paraffin-embedded human melanoma cancer and stomach tissue sections using standard citrate buffer antigen retrieval protocols.

Whether you are exploring mitochondrial dysfunction in cancer biology, investigating metabolic reprogramming, or characterizing Complex I assembly and function, this antibody provides a dependable tool for detecting NDUFB9 across multiple sample types and experimental workflows.

Usage
For Research Use Only. Not for use in diagnostic or therapeutic procedures.

Customer Reviews and Q&A

 Customer Reviews

There are currently no reviews for this product.

Submit a Review here

Target Background

Function
Accessory subunit of the mitochondrial membrane respiratory chain NADH dehydrogenase (Complex I), that is believed to be not involved in catalysis. Complex I functions in the transfer of electrons from NADH to the respiratory chain. The immediate electron acceptor for the enzyme is believed to be ubiquinone.
Gene References into Functions
  1. Down-Regulation of NDUFB9 Promotes Breast Cancer Cell Proliferation, Metastasis by Mediating Mitochondrial Metabolism. PMID: 26641458
  2. Mutant NDUFB9 is a new cause of complex I deficiency. PMID: 22200994
Subcellular Location
Mitochondrion inner membrane; Peripheral membrane protein; Matrix side.
Protein Families
Complex I LYR family
Database Links

HGNC: 7704

OMIM: 601445

KEGG: hsa:4715

STRING: 9606.ENSP00000276689

UniGene: Hs.15977
