TMEM173 Antibody

Code CSB-PA023754LA01HU
Size US$299Purchase it in Cusabio online store
(only available for customers from the US)
  • Western Blot
    Positive WB detected in: MCF-7 whole cell lysate
    All lanes: TMEM173 antibody at 2.7µg/ml
    Secondary
    Goat polyclonal to rabbit IgG at 1/50000 dilution
    Predicted band size: 43 kDa
    Observed band size: 43 kDa

  • IHC image of CSB-PA023754LA01HU diluted at 1:400 and staining in paraffin-embedded human lung cancer performed on a Leica BondTM system. After dewaxing and hydration, antigen retrieval was mediated by high pressure in a citrate buffer (pH 6.0). Section was blocked with 10% normal goat serum 30min at RT. Then primary antibody (1% BSA) was incubated at 4°C overnight. The primary is detected by a biotinylated secondary antibody and visualized using an HRP conjugated SP system.

  • Immunofluorescent analysis of MCF-7 cells using CSB-PA023754LA01HU at dilution of 1:100 and Alexa Fluor 488-congugated AffiniPure Goat Anti-Rabbit IgG(H+L)

The Latest Promotion Free Antibody trial simple
Have Questions? Leave a Message or Start an on-line Chat

Product Details

Full Product Name Rabbit anti-Homo sapiens (Human) TMEM173 Polyclonal antibody
Uniprot No. Q86WV6
Target Names TMEM173
Alternative Names STING1; ERIS; MITA; TMEM173; Stimulator of interferon genes protein; hSTING; Endoplasmic reticulum interferon stimulator; Mediator of IRF3 activation; hMITA; Transmembrane protein 173
Raised in Rabbit
Species Reactivity Human
Immunogen Recombinant Human Stimulator of interferon genes protein (207-379AA)
Immunogen Species Homo sapiens (Human)
Conjugate Non-conjugated

The TMEM173 Antibody (Product code: CSB-PA023754LA01HU) is Non-conjugated. For TMEM173 Antibody with conjugates, please check the following table.

Available Conjugates
Conjugate Product Code Product Name Application
HRP CSB-PA023754LB01HU TMEM173 Antibody, HRP conjugated ELISA
FITC CSB-PA023754LC01HU TMEM173 Antibody, FITC conjugated
Biotin CSB-PA023754LD01HU TMEM173 Antibody, Biotin conjugated ELISA
Clonality Polyclonal
Isotype IgG
Purification Method >95%, Protein G purified
Concentration It differs from different batches. Please contact us to confirm it.
Buffer Preservative: 0.03% Proclin 300
Constituents: 50% Glycerol, 0.01M PBS, pH 7.4
Form Liquid
Tested Applications ELISA, WB, IHC, IF
Recommended Dilution
Application Recommended Dilution
WB 1:500-1:5000
IHC 1:200-1:500
IF 1:50-1:200
Protocols ELISA Protocol
Western Blotting(WB) Protocol
Immunohistochemistry (IHC) Protocol
Immunofluorescence (IF) Protocol
Troubleshooting and FAQs Antibody FAQs
Storage Upon receipt, store at -20°C or -80°C. Avoid repeated freeze.
Lead Time Basically, we can dispatch the products out in 1-3 working days after receiving your orders. Delivery time maybe differs from different purchasing way or location, please kindly consult your local distributors for specific delivery time.

Customer Reviews and Q&A

 Customer Reviews

There are currently no reviews for this product.

Submit a Review here

Target Background

Function
Facilitator of innate immune signaling that acts as a sensor of cytosolic DNA from bacteria and viruses and promotes the production of type I interferon (IFN-alpha and IFN-beta). Innate immune response is triggered in response to non-CpG double-stranded DNA from viruses and bacteria delivered to the cytoplasm. Acts by binding cyclic dinucleotides: recognizes and binds cyclic di-GMP (c-di-GMP), a second messenger produced by bacteria, and cyclic GMP-AMP (cGAMP), a messenger produced by CGAS in response to DNA virus in the cytosol. Upon binding of c-di-GMP or cGAMP, STING1 oligomerizes, translocates from the endoplasmic reticulum and is phosphorylated by TBK1 on the pLxIS motif, leading to recruitment and subsequent activation of the transcription factor IRF3 to induce expression of type I interferon and exert a potent anti-viral state. In addition to promote the production of type I interferons, plays a direct role in autophagy. Following cGAMP-binding, STING1 buds from the endoplasmic reticulum into COPII vesicles, which then form the endoplasmic reticulum-Golgi intermediate compartment (ERGIC). The ERGIC serves as the membrane source for WIPI2 recruitment and LC3 lipidation, leading to formation of autophagosomes that target cytosolic DNA or DNA viruses for degradation by the lysosome. The autophagy- and interferon-inducing activities can be uncoupled and autophagy induction is independent of TBK1 phosphorylation. Autophagy is also triggered upon infection by bacteria: following c-di-GMP-binding, which is produced by live Gram-positive bacteria, promotes reticulophagy. Exhibits 2',3' phosphodiester linkage-specific ligand recognition: can bind both 2'-3' linked cGAMP (2'-3'-cGAMP) and 3'-3' linked cGAMP but is preferentially activated by 2'-3' linked cGAMP. The preference for 2'-3'-cGAMP, compared to other linkage isomers is probably due to the ligand itself, whichs adopts an organized free-ligand conformation that resembles the STING1-bound conformation and pays low energy costs in changing into the active conformation. May be involved in translocon function, the translocon possibly being able to influence the induction of type I interferons. May be involved in transduction of apoptotic signals via its association with the major histocompatibility complex class II (MHC-II).; (Microbial infection) Antiviral activity is antagonized by oncoproteins, such as papillomavirus (HPV) protein E7 and adenovirus early E1A protein. Such oncoproteins prevent the ability to sense cytosolic DNA.
Gene References into Functions
  1. We present physiological evidence that UBXN3B positively regulates stimulator-of-interferon genes (STING) signaling. Mechanistic studies demonstrate that UBXN3B interacts with both STING and its E3 ligase TRIM56, and facilitates STING ubiquitination, dimerization, trafficking, and consequent recruitment and phosphorylation of TBK1. PMID: 29899553
  2. STAG2 deficiency induces interferon responses via cGAS-STING pathway and restricts virus infection. PMID: 29662124
  3. STING-IRF3 pathway promotes hepatocyte injury and dysfunction by inducing inflammation and apoptosis and by disturbing glucose and lipid metabolism. PMID: 29106945
  4. Data show that both cyclic GMP-AMP synthase (cGAS) and interferon-gamma inducible protein 16 (IFI16) are required for the activation of membrane protein STING (STING) and an innate immune response to exogenous DNA and DNA viruses. PMID: 28194029
  5. PUMA promotes the cytosolic release of mitochondrial DNA and activation of the DNA sensors DAI/Zbp1 and STING, leading to enhanced RIP3 and MLKL phosphorylation in a positive feedback loop. PMID: 29581256
  6. identified nitro-fatty acids as endogenously formed inhibitors of STING signaling and propose for these lipids to be considered in the treatment of STING-dependent inflammatory diseases. PMID: 30061387
  7. Cells of human individuals carrying HAQ TMEM173, which encodes a common hypomorphic variant of STING, were largely or partly defective in inducing type I IFNs and proinflammatory cytokines upon infection. PMID: 29263110
  8. Our studies indicate that the (extracellular vesicles) EVs released by HSV-1-infected cells carry innate immune components such as STING and other host and viral factors; they can activate innate immune responses in recipient cells and inhibit HSV-1 replication. The implication of these data is that the EVs released by HSV-1-infected cells could control HSV-1 dissemination promoting its persistence in the host. PMID: 29976662
  9. data demonstrate that numerous RNA viruses evade cGAS/STING-dependent signaling and affirm the importance of this pathway in shaping the host range of ZIKV. PMID: 29915078
  10. Immune activation of STING requires palmitoylation at the Golgi. PMID: 27324217
  11. In the Title. PMID: 27554814
  12. This study demonstrated that HSV-1 tegument protein VP22 counteracts the cGAS/STING-mediated DNA-sensing antiviral innate immunity signaling pathway by inhibiting the enzymatic activity of cGAS. PMID: 29793952
  13. an electrophoretic mobility shift assay showed that signal transducers and activators of transcription 1 (STAT1) attach to the GAS motif on the human STING promoter region. This indicates that IFN-gamma/Janus kinases/STAT1 signaling is essential for the STING upregulation in human keratinocytes. PMID: 29143896
  14. The cGAS-STING cascade contributes to antibacterial defense against L. pneumophila in mice and men, and provides important insight into how the common HAQ TMEM173/STING variant affects antimicrobial immune responses and susceptibility to infection. PMID: 29298342
  15. pharmacological activation of STING in macrophages and hepatocytes induces host innate responses that can efficiently control hepatitis B virus replication. Hence, despite not playing a significant role in host innate immune response to HBV infection of hepatocytes, STING is potentially a valuable target for immunotherapy of chronic hepatitis B. PMID: 28717041
  16. summarize recent findings that have pointed towards the STING pathway as an innate immune sensing mechanism driving type I interferon production in the tumor context PMID: 28639100
  17. this review summarizes important features of the STING activation pathway and recent highlights about the role of STING in bacterial infections by Chlamydia, Listeria, Francisella, Brucella, Shigella, Salmonella, Streptococcus, and Neisseria genera, with a special focus on mycobacteria. PMID: 28625530
  18. STING serves to detect - and promote immune defense against - DNA viruses and intracellular bacteria, as described in its initial discovery. The role of STING has since been expanded to include tumor surveillance and immune responses to cancer; indeed, defective STING responses are associated with certain cancers. PMID: 28724326
  19. C11 depends on signaling through STING to produce antiviral type I interferon, which further supports its potential as a therapeutic drug or research tool. PMID: 29263267
  20. This study demonstrates that the HCMV tegument protein pp65 inhibits IFN-beta production by binding and inactivating cGAS early during infection. In addition, this inhibitory activity specifically targets cGAS, since it can be bypassed via the addition of exogenous cGAMP, even in the presence of pp65. Notably, STING proteasome-mediated degradation was observed in both the presence and absence of pp65. PMID: 29263269
  21. The DNA binding domain of Ku70 was essential for formation of the Ku70-STING complex. Knocking down STING in primary human macrophages inhibited their ability to produce IFN-lambda1 in response to transfection with DNA or infection with the DNA virus HSV-2 (herpes simplex virus-2); STING mediates the Ku70-mediated IFN-lambda1 innate immune response to exogenous DNA or DNA virus infection. PMID: 28720717
  22. Data show that human cytomegalovirus (HCMV; human betaherpesvirus 5) glycoprotein US9 inhibits the IFN-beta response by targeting the mitochondrial antiviral-signaling protein (MAVS) and stimulator of interferon genes (STING)-mediated signaling pathways. PMID: 29317664
  23. In the current study, we studied the role of MITA (Mediator of IRF3 Activation), a regulator of innate immunity, in the regulation of autophagy and its implication in cell death of breast cancer cells. Here, we report that MITA inhibits the fusion of autophagosome with lysosome as evident from different autophagy flux assays PMID: 28366813
  24. these studies demonstrate that transcription factors CREB and c-Myc maintain the transcriptional activity of STING PMID: 27835584
  25. TheTREX1 and STING, which are opposing regulators of the cytosolic DNA-sensing pathway. PMID: 28475463
  26. STING-regulated pathways underlie the pathogenesis of many diseases including infectious diseases and cancers. It has also become evident from these studies that STING is a promising therapeutic target for the treatment of cancer. PMID: 26980676
  27. using a murine HNSCC model that does not express STING, we demonstrate that STING ligands are an effective therapy regardless of expression of STING by the cancer cells PMID: 29135982
  28. Human T-lymphotropic virus 1 Tax protein impairs K63-linked ubiquitination of STING and disrupted the interactions between STING and TBK1 to evade host innate immunity. PMID: 28119118
  29. STING activated an antiviral/type I interferon response with live but not killed S. aureus. PMID: 28704551
  30. study identifies the AIM2 inflammasome and cGAS/IFI16-STING-type I IFN pathway as a novel mechanism for host innate immunity to the ALVAC vaccine vector. PMID: 28947539
  31. NEMO was critically involved in the cGAS-STING pathway. PMID: 28939760
  32. Studied association of genetic variants of the MAVS, MITA and MFN2 genes with leprosy in Han Chinese from Southwest China; found no association between the variants and susceptibility to leprosy. PMID: 27553710
  33. both IL-6 and RIG-I are downstream molecules of STING along the DNA sensor pathway. PMID: 28806404
  34. our data provide an important insight into STING-mediated induction of type I and III IFNs and subsequent antiviral signaling pathways that regulate VZV replication in human dermal cells. PMID: 28647346
  35. STING, a critical innate sensor, also functions intrinsically in cells of the adaptive immune system to inhibit proliferation. PMID: 28484079
  36. We discuss three newly described monogenic autoinflammatory diseases [deficiency of adenosine deaminase 2 (DADA2), a subtype of macrophage activation syndrome (MAS), and stimulator of interferon genes (STING)-associated vasculopathy with onset in infancy (SAVI)], discuss the possibilities of somatic mosaicism and digenic inheritance, and give an update on new concepts in pathways involved in familial Mediterranean fever PMID: 27362340
  37. Human Cytomegalovirus tegument protein UL82 negatively regulates STING-mediated signaling. PMID: 28132838
  38. Structural analysis indicates that the 3 disease-associated mutations at positions 206, 281, and 284 of the STING protein define a novel cluster of amino acids with functional importance in the regulation of type I interferon signaling PMID: 28087229
  39. a critical role of p38-mediated USP21 phosphorylation in regulating STING-mediated antiviral functions and identifies p38-USP21 axis as an important pathway that DNA virus adopts to avoid innate immunity responses. PMID: 28254948
  40. We conclude that the R71H-G230A-R293Q (HAQ) of TMEM173 is a null TMEM173 allele. PMID: 27927967
  41. The authors found that the herpes simplex virus 1 UL46 protein interacts with and colocalizes with STING. PMID: 28592536
  42. Essential roles of the cGAS-cGAMP-STING pathway. [review] PMID: 27706894
  43. These results suggest that pDCs sense cytosolic DNA and cyclic dinucleotides via the cGAS-STING pathway and that targeting this pathway could be of therapeutic interest. PMID: 27125983
  44. Human herpesvirus 1 ICP27 interacted with TBK1 and STING in a manner that was dependent on TBK1 activity and the RGG motif in ICP27 and inhibited type I IFN induction through the cGAS-STING-TBK1 pathway in human macrophages. PMID: 27234299
  45. Multivariate analysis supported TMEM173 as an independent prognostic factor. PMID: 27814372
  46. The mitochondrial damage-cGAS-STING-IRF3 pathway is critically involved in metabolic stress-induced endothelial inflammation. PMID: 28302626
  47. These data uncover a promycobacterial role for STING-dependent OASL production during Mycobacterium leprae infection that directs the host immune response toward a niche that permits survival of the pathogen. PMID: 27190175
  48. A heterozygous gain-of-function mutation in STING can cause familial chilblain lupus. PMID: 27566796
  49. cGAs recognizes bacterial/viral DNA, and is a strong activator of STING that can further activate IRF3 and subsequent type I interferon production. (Review) PMID: 27696330
  50. In the present study, the authors found that herpes simplex virus 1 tegument protein UL41 was involved in counteracting the cGAS/STING-mediated DNA-sensing pathway. PMID: 28077645

Show More

Hide All

Involvement in disease STING-associated vasculopathy, infantile-onset (SAVI)
Subcellular Location Endoplasmic reticulum membrane; Multi-pass membrane protein. Cytoplasm, perinuclear region. Endoplasmic reticulum-Golgi intermediate compartment membrane; Multi-pass membrane protein. Cytoplasmic vesicle, autophagosome membrane; Multi-pass membrane protein. Mitochondrion outer membrane; Multi-pass membrane protein. Cell membrane; Multi-pass membrane protein.
Protein Families TMEM173 family
Tissue Specificity Ubiquitously expressed. Expressed in skin endothelial cells, alveolar type 2 pneumocytes, bronchial epithelium and alveolar macrophages.
Database Links

HGNC: 27962

OMIM: 612374

KEGG: hsa:340061

STRING: 9606.ENSP00000331288

UniGene: Hs.379754
